Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of roller 26ton in China. Please feel free to buy cheap roller 26ton for sale here from our factory. Quality products and reasonable price are available.
SSR260AC maintain（Roller 26ton） an efficient work area with 80% load rate. The industry's first vibratory roller energy-saving control technology,. Fuel consumption of SSR260AC （Roller 26ton）reduced by 10%, noise reduced by 14% .SSR260AC（Roller 26ton） has continuously variable speed, forward and backward reversal can immediate response. SSR260AC （Roller 26ton）has hydraulic transmission, start it does not hurt the ground, construction efficiency increased by 20%. Hydraulic system can transfer pressure immediately.SSR260AC has quick braking response and short braking distance.
Type | SSR260AC-8H |
Dimensions | 6500*2380*3300 |
Drum Width | 2170mm |
Excitation Force | 416/295kN |
Nominal Amplitude | 1.9/0.95mm |
Vibration Frequency | 27/32Hz |
Drum Static Linear Load | 610N/cm |
Emission | CHINA Ⅲ |
Engine Model | WP6G200E331 |
Rated Power | 147kW |
Theoretical Gradeability Vibratory | 30% |
Travel Speed | 0~8km/h |
Ground Clearance | 440mm |
Operating Weight | 26T |
Weight at Drum | 13T |
Weight at Rear Axle | 13T |
Product Feature
1.High security
Full hydraulic products, mechanical price
2.High quality construction
Compacted pavement effect is 15% higher than mechanical
3.Low use cost
One lever operation, the vibration started or stopped is smooth and soft.
Product Technology
1.Intelligent engine speed change
SSR200AC maintain an efficient work area with 80% load rate. The industry's first vibration roller energy-saving control technology (2 invention patents), fuel consumption than mechanical fuel saving 10%. Industry's first intelligent fan control system (1 invention patent), 14% lower than mechanical noise. Save fuel and reduce noise.
2.High construction efficiency
Infinitely variable speed, forward and backward direction change instantly. Hydraulic transmission, no scratch at the start, construction efficiency increased by 20%, lower fuel consumption per unit of compacted road surface.
3.Hydraulic wheel brake
Hydraulic system can transfer pressure instantly, brake reaction time is short, brake distance is short. Hydraulic braking system is simple in structure, mature in technology and reliable in braking. Hydraulic brake system requires no special maintenance.The system has energy storage circuit, automatic reserve brake pressure, even in the case of engine flameout, press the brake pedal can quickly brake, stop.
4.Vibration bearing rat bag lubrication technology
The vibration bearing adopts the patented bag lubrication technology to ensure that the bearing is lubricated 360° continuously. The lubrication structure is not immersion type lubrication, with the advantages of less lubricating oil, no oil pumping function of the vibrator, and less heat. Greatly prolong the service life of bearings
5.Full hydraulic drive
One-rod operation, front and back reversing operation, simple and convenient, good control.
