Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of wheel loader sl30wn in China. Please feel free to buy cheap wheel loader sl30wn for sale here from our factory. Quality products and reasonable price are available.
1.Wheel loader SL30WN engine use Weichai WP6G125E333 engine, which has powerful power, reliable performance, high efficiency and energy saving.
2.Single-stage single-phase three-element torque converter, fixed-axis power shift gearbox to transmit power. The power matching is good, the movement is smooth, and the work is more powerful. Split structure, easy maintenance. The speed selection of four forward gears and two backward gears is suitable for various harsh working conditions and moves more quickly.
3.Wheel loader SL30WN optimized loading and unloading height is 3057mm, which is higher in the industry. That is to ensure superior loading performance, but also to ensure greater torsional moment. The loading and unloading operation has a wide range and high efficiency! The bucket can be automatically leveled, three items and 9s, the industry is small, and the driver's labor intensity is low.
4.Wheel loader SL30WN optimized wheelbase of 2700mm ensures excellent site adaptability and flexibility, as well as operation stability, and easy loading and unloading operations.
5.Wheel loader SL30WN structural parts of the main engine are optimized by finite element design, adopting plate structure, automatic welding by robot, anti-load and anti-distortion, the whole machine is firm and compact, and has good stability.
6.Wheel loader SL30WN swing frame is designed to swing up and down by 12°, so that the loader can land more effectively on rough roads, with greater adhesion, better stability
7.The front and rear racks adopt the dual-positioning hinged structure with its own technology, which is reliable in use and convenient in maintenance.
8.Various working devices such as wood grabbers, grass grabbers, coal loading buckets, side dump buckets and breakers are available for selection.
Rated bucket capacity | 1.7~2.2m³ |
Rated loading capacity | 3t |
Operating weight | 10500kg |
Rated power | 92kW |
Max breakout force | 105kN |
Max traction force | 110K |
Boom lift time | 5.1s |
three and time | 9.0s |
Maximum loading and unloading height (extended arm) | 3057mm |
Corresponding unloading distance | 906mm |
Maximum loading and unloading height (long arm King Kong) | 3200mm |
Corresponding unloading distance | 886mm |
Maximum gradeability | 30° |
Engine model | Weichai WP6G125E333 |
Rated power | 92 |
Rated speed | 2000r/min |
