Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 180hp grader in China. Please feel free to buy cheap 180hp grader for sale here from our factory. Quality products and reasonable price are available.
180HP Grader SG18 has 6 forward gears and 3 reverse gears, electro-hydraulic control power shift transmission can choose the best gear according to the working condition, to achieve the best match between driving and operation.
Integrated three-section drive axle, built-in imported non-rotating automatic limited slip differential, improve off-road performance, stable and reliable driving.
The balance box can swing vertically at an Angle of 15°, and the heavy roller chain drive ensures the machine has better terrain adaptability. It can meet the normal operation under special road conditions, stable power output and strong driving force.
Special technology of external gear working device, driving torque, strong resistance to external impact.
The blade with a wider Angle adjustment range (37° to 83°) improves material control and significantly improves the efficiency of the grader, especially when dealing with dry materials and clay.
Compared with similar products, the grader has the capacity of forward two gear full load shovel, which can significantly improve the production efficiency.
The connecting rod type swing frame has strong resistance to external impact, and is suitable for working conditions with large amount of work and bad working environment.
Technical characteristics
Power system
Weichai electric control engine, emissions meet the national non-road machinery stage Ⅲ emission requirements, intelligent and efficient, parts versatility, low maintenance cost.
Reasonable matching, high transmission efficiency, low fuel consumption.
Three-stage air filter and three-stage fuel filter, effectively extend the service life of the engine.
Driving environment
High efficiency shock absorbing seat, maximizes the operation comfort, the operator does not fatigue for a long time.
The cab is equipped with standard air conditioning, overall sealed vibration reduction system, double-layer seal, sound-absorbing sponge, low vibration noise, the noise can be as low as 80 decibels below.
Intelligent display and control terminal integrated instrument, fault online detection and alarm, to provide more user-friendly driving experience, driving environment comfortable and safe.
User-friendly configuration is complete, water wiper, coat hook, shade, radio, cigarette lighter, storage box, fire extinguisher is fully equipped to provide more user-friendly driving experience.
Adaptability to work
The electric hydraulic control power shift transmission produced by ZF technology.
180HP Grader SG18 has the first 6 gears and the last 3 gears, which can choose the best gear according to the operation road conditions to achieve the best collocation of walking and operation;
Three-section drive axle, built-in imported no-SPIN automatic anti-slip differential, smooth and reliable transmission.
Balance box adopts heavy roller chain drive, the machine through and terrain adaptability is better, can meet the normal construction operation under special road conditions, power output is stable, driving force is strong.
Operating performance
External gear working device with independent patented technology, large transmission torque, strong resistance to external impact.
The larger Angle range of the scraper improves the material control ability, especially useful in dealing with dry materials and clay.It can significantly improve the operation efficiency of the grader.
180HP Grader SG18 adopts the connecting rod type swing frame, strong resistance to external impact, suitable for large amount of work, bad working environment.
Easy maintainability
The hydraulic pin cylinder only needs one person to complete the operation of the swing frame, and there is no safety hazard, convenient for users to use.
The electrical wiring harness adopts seamless bellows and splitter, with high protection grade.
The maintenance-free battery is placed at the back of the device and has a large battery life.The core electrical and hydraulic components are imported with stable and reliable quality and high reliability.
Double side double door wide opening cover, daily maintenance and maintenance at your fingertips.
Description | Unit | Parameter value |
Engine model | 6CTA8.3-C190-Ⅱ | |
Rated power/speed | kW/rpm | 142/2200 |
Overall dimension (standard) | 8900x2625x3420 | |
Total weight (standard) | kg | 15400 |
Tire specification | 17.5-25 | |
Ground clearance (front axle) | mm | 430 |
Tread | mm | 2156 |
Space of front and rear axles | mm | 6219 |
Space of middle and rear wheels | mm | 1538 |
Forward velocity | km/h | 5/8/11/19/23/38 |
Reverse speed | km/h | 2005/11/23 |
Tractive effort f=0.75 | kN | ≥79 |
Maximum gradeability | % | ≥25 |
Tire inflation pressure | kPa | 260 |
Working system pressure | MPa | 18 |
Transmission pressure | MPa | 1.3-1.8 |
Maximum steering angle of front wheel | ±50° | |
Maximum slant angle of front wheel | ±17° | |
Maximum oscillating angle of front axle | ±15° | |
Maximum oscillating angle of equilibrium box | Front15° Rear15° | |
Maximum steering angle of frame | ±27° | |
Minimum turning radius | m | 7.3 |
