Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of d6 crawler dozer in China. Please feel free to buy cheap d6 crawler dozer for sale here from our factory. Quality products and reasonable price are available.
SHANTUI for d6 dozer is a bulldozer developed for harsh environments. With remote control and other operation methods, it can adapt to various complex and dangerous working conditions.
The fuel tank of SHANTUI for d6 dozer is increased to 360L, which can achieve 14-hour long battery life; the standard 810mm single-tooth crawler has high flatness when moving clay; it is equipped with engine intake heating function, which solves the problem that the engine is not easy to run in cold and severe weather. Startup problem.
The whole cab of SHANTUI for d6 dozer is sealed with a shock absorption system, which reduces the noise inside the car by 3~4dB. Seats and armrests can be adjusted in a wide range to provide the driver with the most comfortable operating environment.
Excellent construction performance in narrow sites, strong component versatility, and low maintenance costs.
Mainly used for backfill earthwork and push of other bulk materials. It is suitable for highway, railway, water conservancy construction, land development and factory and mine operations.
Parameter name | DH17-C2 XL (Extended version) | DH17-C2 LGP（Super-wetland version） | DH17-C2 WH (Environmental sanitation version) | DH17-C2 DS (Desert version) | DH17-C2 RS (Rock version) | DH17-C2 FL (Forestry version) | DH17-C2 CH (Coal version) |
Performance parameters | |||||||
Operating weight (Kg) | 18340 (With traction frame)/19241 (With ripper) | 20200 | 20140 | 20600 | 19176 | 19985 (With traction frame)/21725 (With winch) | 18700 |
Ground pressure (kPa) | 67.2 | 31.2 | 31.1 | 43.3 | 58.75 | 55.5 (With traction frame)/60.7 (With winch) | 57.3 |
Engine | |||||||
Engine model | WP10 | WP10 | WP10 | WP10 | WP10 | WP10 | WP10 |
Rated power/rated speed (kW/rpm) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) |
Overall dimensions | |||||||
Overall dimensions of machine (mm) | 5250*3420*3080 | 5340*4150*3091 | 5586*4150*3091 | 5340*4150*3091 | 5250*3420*3080 | 6320*3438*3210 | 5250*3420*3080 |
Driving performance | |||||||
Forward speed (km/h) | 0～10 | 0～10 | 0～10 | 0～10 | 0～10 | 0～10 | 0～10 |
Reversing speed (km/h) | 0～10 | 0～10 | 0～10 | 0～10 | 0～10 | 0～10 | 0～10 |
Chassis System | |||||||
Center distance of track (mm) | 1880 | 2350 | 2350 | 2350 | 1880 | 1880 | 1880 |
Width of track shoes (mm) | 510/560/610 | 1100/950 (Swamp type)/900 (Single grouser) | 1100/950 (Swamp type) | 810 (Single grouser)/1100/950 (Swamp type) | 610 | 610 | 610/510/560 |
Ground length（mm） | 2675 | 2935 | 2935 | 2935 | 2675 | 2935 | 2675 |
Tank capacity | |||||||
Fuel tank (L) | 305 | 305 | 305 | 305 | 305 | 305 | 305 |
Working device | |||||||
Blade type | Semi-U blade/straight tilting blade | Straight tilting blade | Sanitation blade | Straight tilting blade | Rock blade | Angle Blade | Coal blade |
Digging depth (mm) | 520 | 485 | 485 | 485 | 520 | 485 | 520 |
Ripper type | Three-shank | —— | —— | —— | —— | —— | —— |
Ripping depth (mm) | 475 | —— | —— | —— | —— | —— | —— |
