Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of shantui bulldozer sd22 in China. Please feel free to buy cheap shantui bulldozer sd22 for sale here from our factory. Quality products and reasonable price are available.
The Shantui Bulldozer Sd22 adopts a hexahedral shock-absorbing cab, which is beautiful in appearance, wide in field of vision and comfortable in operation;
shantui for bulldozer sd22 Adopt high-efficiency supercharged engine, with good power, reliability and durability;
Shantui Bulldozer Sd22 Adopt advanced technologies such as improved hydraulic transmission and hydraulic control, advanced and reasonable structure, reliable quality, light and flexible operation; Adopt Shantui patented technologies such as centralized lubrication, centralized pressure measurement, automatic crawler tightening, etc., and GPS satellite positioning service system;
It can be equipped with various working devices such as straight-tilting shovel, angle shovel, U-shaped shovel, semi-U-shaped shovel, single-tooth/three-tooth ripper, mechanical winch, etc.
Parameter name | SD22 (Standard version) | SD22C (Coal version) | SD22W (Rock version) | SD22F (Forestry version) | SD22D (Desert version) | SD22E (Extended version) | SD22R (Environmental sanitation version) | SD22S (Wetland version) |
Performance parameters | ||||||||
Operating weight (Kg) | 23450 | 24000 | 23600 | 24700 | 24600 | 24600 | 26000 | 25700 |
Ground pressure (kPa) | 66 | 57.5 | 66 | 64 | 56 | 66 | 36 | 35.2 |
Engine | ||||||||
Engine model | WP12/QSNT-C235 | WP12/QSNT-C235 | QSNT-C235 | QSNT-C235 | QSNT-C235 | QSNT-C235 | WP12/QSNT-C235 | WP12/QSNT-C235 |
Rated power/rated speed (kW/rpm) | 175/1800 | 175/1800 | 175/1800 | 175/1800 | 175/1800 | 175/1800 | 175/1800 | 175/1800 |
Overall dimensions | ||||||||
Overall dimensions of machine (mm) | 5495*3725*3402 | 5820*4200*3402 | 5495*3725*3402 | 5495*3725*3402 | 5495*3725*3402 | 5495*3725*3402 | 6290*4365*3745 | 6290*4365*3402 |
Driving performance | ||||||||
Forward speed (km/h) | F1:0-3.6 | F1:0-3.6 | F1:0-3.6 | F1:0-3.6 | F1:0-3.6 | F1:0-3.6 | F1:0-3.6 | F1:0-3.6 |
Reversing speed (km/h) | R1:0-4.3 | R1:0-4.3 | R1:0-4.3 | R1:0-4.3 | R1:0-4.3 | R1:0-4.3 | R1:0-4.3 | R1:0-4.3 |
Chassis System | ||||||||
Center distance of track (mm) | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2250 | 2250 |
Width of track shoes (mm) | 560/610/660 | 660 | 560/610/660 | 610/660 | 660 | 560/610/660 | 910 | 910 |
Ground length(mm) | 2730 | 2730 | 2730 | 2730 | 3050 | 3050 | 3480 | 3480 |
Tank capacity | ||||||||
Fuel tank (L) | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 |
Working device | ||||||||
Blade type | Straight tilting blade , Angle Blade, U-shaped Blade and Semi-U blade | Coal blade | Rock straight tilting blade, rock angle blade, rock U-blade, and rock semi-U blade | Straight tilting blade , Angle Blade, U-shaped Blade and Semi-U blade | Straight tilting blade , Angle Blade, U-shaped Blade and Semi-U blade | Straight tilting blade , Angle Blade, U-shaped Blade and Semi-U blade | Sanitation blade | Straight tilting |
Digging depth (mm) | 540 | 538 | 540 | 540 | 540 | 540 | 550 | 550 |
Ripper type | Single-shank three-shank | Single-shank three-shank | Single-shank three-shank | Single-shank three-shank | Single-shank three-shank | Single-shank three-shank | —— | —— |
Ripping depth (mm) | 695 (Single-shank) and 666 (Three-shank) | 695 (Single-shank) and 666 (Three-shank) | 695 (Single-shank) and 666 (Three-shank) | 695 (Single-shank) and 666 (Three-shank) | 695 (Single-shank) and 666 (Three-shank) | 695 (Single-shank) and 666 (Three-shank) | —— | —— |
