Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 3.5 t excavator in China. Please feel free to buy cheap 3.5 t excavator for sale here from our factory. Quality products and reasonable price are available.
3.5 t excavator Yanmar engine comes standard, conforms to Euro III emission standard, EPA certification, large torque, strong power, 3.5 t excavator energy saving and fuel saving. The load-sensing system realizes the perfect match between the engine and the main pump, accurately provides the flow, and improves the operation 3.5 t excavator
DRMENSTONS | |
overall length(erm lowered) (mm) | 4400 |
overall height(mm) | 2200 |
width (mm) | 1530/1600 |
Track witdth (mm) | 300 |
Total track length (mm) | 2175 |
Track gauge | 1703 |
Platform ground clearance (mm) | 557 |
Working Range | |
Max.Digging Height | 4450 |
Max.Dumping Height | 3050 |
Max.Digging Depth | 2545 |
Max.Digging Distanc | 4630 |
Max.Digging Radius | 4730 |
Min .Radius of gyration | 1820 |
Max.Lifting height of earth shovel | 359 |
Max.Digging depth of dozer | 268 |
Min.Tail swing radius | 1170 |
ENGINE | |
Model | changchai490/ Yanmar 3TNV88/ country 3 discharge |
Output (kw/rpm) | 34/2200 20/2200 36.8KW |
Cooling method | wter-cooling Diesel engine |
HYDRAULIC SYSTEM | |
Operating pressure | 22mpa |
walking motor | tow speed plunger |
Rotary motor | variable plunger |
The Main Pump | 32cc plunger 32cc |
Flow | 99/MIN |
PERFORMANCE PARAMETER | |
Climbing ability | 35° |
Max.digging force Bucket/lever (iso) | 55.6kn(5560) |
Track speed (High/low) | 2.7/4.6km/h |
Unit swing speed | 9-11r/min |
Rail contact pressure on the ground | 34.8kpa (0.355kgf/cm³) |
Specification | |
Bucket Capacity | 0.26 m³ |
Fuel reservoir | 60L |
Hydraulic tank capacity | 75L |
Operating weight | 3600kg |
