Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of famous 3 tonne digger in China. Please feel free to buy cheap famous 3 tonne digger for sale here from our factory. Quality products and reasonable price are available.
Famous 3 tonne digger Changchai 390 comes standard with Country 2, meets Euro III emission standards, and is EPA certified. It features large torque,infront 3 tonne digger strong power, and energy saving. The load-sensing system realizes the perfect match between the engine and the main pump, accurately provides the flow, and improves the operation infront 3 tonne digger
Overall Dimensions | |
Total Length (mm) | 4180 |
Total Width (mm) | 1400 |
Total Height (mm) | 2128 |
Ground Clearance (mm) | 458 |
Total Weight (kg) | 2700 |
Ground Pressure (kpa) | 38 |
Performance | |
Max.Digging Height (mm) | 3900 |
Max.Digging Radius (mm) | 4040 |
Max.Digging Depth (mm) | 2500 |
Max.Dumping Height (mm) | 2600 |
Slewing Angle | 360° |
Grade Ability | 25° |
Travel Speed (km/h) | 2.6 |
Bucket Capacity (m³) | 0.095 |
Bucket Width (mm) | 500 |
Swing angle of boom (°)L/R | 70/50 |
Track | |
Track Gauge (mm) | 1150 |
Track Width (mm) | 250/260 |
Track Length (on ground)(mm) | 2300 |
Hydraulic System | |
Main pump | Triple pump |
Main Pressure (Mpa) | 18 |
Max.Rpm of the pump (r/min) | 2500 |
Pump Displacement (ml/r) | 28 |
Engine | |
Model | Changchai390 /Yanmar 3TNV88 |
Output(KW/rpm) | 20/2200 19.6/2200 |
