Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 215hp road grader in China. Please feel free to buy cheap 215hp road grader for sale here from our factory. Quality products and reasonable price are available.
Feature of Product
The excellent industrial design team made great efforts to create the perfect shape of the 215hp road Grader 4215D, and the cab was awarded the invention patent (ZL201630260390.6). Panoramic field of view, the control field of vision is extremely shocking. The cab is optional with ROPS & FOPS function.
The 215hp road Grader 4215D is equipped with German high-quality transmission technology ZF gearbox as standard, with electronic shifting, high transmission efficiency, low fuel consumption, low noise, and an average of 10,000 hours without unpacking.
The industry's best working device design, the 4512D is equipped with a rolling disk working device and an overload protection worm gear box as standard, with flexible rotation, high precision, sand and dust resistance, no adjustment, and high strength. Lift the blade directly onto the trolley, without pulling out the pin and side swinging tow frame, and the shipping efficiency is high.
The engine hood adopts an electronically controlled integral front flip, and the front and rear frames are hinged with a large span up and down, making daily maintenance more convenient.
Model | 215hp road Grader 4215D |
Operating weight | 15500 kg |
Weight on front wheels | 4650 kg |
Weight on rear tandem | 10850 kg |
Drawbar pull | 86 kN |
Model | / |
Emission regulation | Tier 2 / Stage II |
Rated power | 142 kW (193 hp) @ 2200 rpm |
Net power | 128 kW (174 hp) @ 2200 rpm |
Type | Power shift |
Speeds | 6f / 3r |
Maximum travel speed, forward | 42 km/h |
Maximum travel speed, reverse | 26.2 km/h |
Turning radius | 7300 mm |
Articulation angle | ±20c |
Maximum overall height | 3500 mm |
Width over tires | 2600 mm |
Blade width | 3960 mm |
Overall length | 9265 mm |
