Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 3 wheel electric forklift in China. Please feel free to buy cheap 3 wheel electric forklift for sale here from our factory. Quality products and reasonable price are available.
Product Highlights
3 wheel electric forklift More efficient
Full AC drive system, imported wet brakes.
The front wheels are driven independently by dual motors, the direction and speed are controlled by the computer, the turning radius is small, and it is flexible and convenient.
Open the balance cover for electrical maintenance.
3 wheel electric forklift More reliable
The three-stage full-free mast adopts the front double large cylinder design, which greatly increases the driving visibility.
3 wheel electric forklift More comfortable
Fully ergonomically designed integrated operating handle, which integrates various control buttons such as lifting, lowering, forward tilt, backward tilt, side shift, emergency stop switch, horn, light control, etc., all operations can be completed with one hand , greatly improving the operation efficiency.
The LED display instrument is easy to operate, and the vehicle data and information are more abundant and intuitive.
Specifications | ||
Unit | FB20H-B1 | FB25H-J1 |
Characteristics | Power battery | lithium battery |
Capacity | 2000kg | 2500kg |
Center of load | 500mm | 500mm |
Lifting height | 3000mm | 3000mm |
Free lifting height | 145mm | 145mm |
Forks L×W×H | 920×122×40 | 1070×122×40 |
Min.turning radius | 2000mm | 2020mm |
Min right angle stacking width | 3754mm | 3924mm |
Min.ground clearance (mast) | 110mm | 110mm |
Overhead guard height | 2196mm | 2196mm |
Front overhang | 434mm | 434mm |
Rear overhang | 290mm | 312mm |
Max.traveling speed(loaded) | 14.5km/h | 14.5km/h |
Max.lifting speed(loaded/unloaded) | 280/490mm/s | 330/510mm/s |
Gradeability | 20% | 18% |
Dimensions | 3195mm | 3367mm |
Overall width | 1186mm | 1186mm |
Mast lowered height | 1990mm | 1990mm |
Mast extended height | 4040mm | 4040mm |
Chassis Tire Front | 23x9-10-16PR | 23x9-10-16PR |
Rear | 18x7-8-14PR | 18x7-8-14PR |
Wheelbase | 1550mm | 1550mm |
Tread width Front/Rear | 961/950mm | 961/950mm |
Curb weight None-load | 4060kg | 4350kg |
Powertrain BatteryVoltage/Capacity | 600V/Ah | 630V/Ah |
Battery model | 5PzS600H | D-630 |
Motor Traveling | YQD11.5-4-6190 | XYQ-11-6H |
Auxiliary | XQD-10-3S | XYQD-14-1H |
Rated power Travelin | 11.5kw | 11kw |
Auxiliary | 10kw | 14kw |
Working pressure | 17.5Mpa | 17.5Mpa |
