Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of payloader 7ton in China. Please feel free to buy cheap payloader 7ton for sale here from our factory. Quality products and reasonable price are available.
Product Features
The payloader 7ton LG876N is equipped with an engine with a power of 199KW, which is powerful and efficient, and has reliable quality.
The payloader 7ton LG876N is equipped with a ZF fixed-shaft fully automatic electro-hydraulic proportional shift gearbox and a heavy-duty drive axle. High reliability and stronger applicability under heavy load conditions.
The fixed variable confluence hydraulic system can automatically adjust the displacement of the pump according to the size of the working load, reduce the overflow loss and reduce the fuel consumption.
The hydraulic system adopts a large number of international brand components, and the performance is more stable.
The multi-function pilot handle can move forward and backward with the luxury seat, with advanced functions and simple, comfortable and convenient operation.
The 7-inch independent LCD instrument on the right can accurately display the working status of the main components, and has the visual function of reversing image at the same time.
The super-long wheelbase is centrally arranged, and the bridge load distribution is reasonable, and the heavy-load adaptability is further improved.
payloader 7ton LG876N adopts solid pin shaft, and the steel plate is grooved for oil filling, which improves the service life of the pin shaft.
Super-strong and heavy-duty structural parts, adopting a board-box structure and a large-structure front frame, with reasonable stress distribution, strong load-bearing capacity and strong torsion resistance.
The standard 750/65R25/L-3 radial wide-base tubeless tire has a large tire contact area and high overall stability and bearing capacity.
Model | payloader 7ton LG876N | |
Rated bucket capacity | m³ | 4.2-7.0 |
Rated load capacity | kg | 7000 |
Rated power | Kw/rpm | 199/2200 |
Overall operating weight | kg | 23500±300 |
Max. traction force | kN | 200 |
Max. Rising power | kN | 240 |
Unload height | mm | 3610 |
