Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 2m road planer in China. Please feel free to buy cheap 2m road planer for sale here from our factory. Quality products and reasonable price are available.
Technical Features
Efficient
The 630-horsepower EFI engine with a working weight of 33 tons has high efficiency and good adaptability to working conditions.
The maximum speed of the conveying belt is high, the conveying capacity is strong, and the maximum speed can be independently calibrated.
The multi-function handle, one-button operation, and the storage function of multiple sets of milling depth settings make the operation more convenient.
The conveyor belt is designed with a large swing angle, and the material receiving range is wide.
Intelligent
2m road planer SM200M-C6 has functions such as emergency operation and construction information management.
2m road planer SM200M-C6 has a complete fault self-diagnosis and alarm and prompt system.
Parameters such as steering zero position, depth of cut zero position, column lifting speed and travel handle can be calibrated online.
2m road planer SM200M-C6 can be equipped with a remote control system to meet special conditions.
Affordable
2m road planer SM200M-C6 adopts temperature-controlled fan technology, and the whole machine has better fuel economy.
The water system has the alarm function of water shortage and blockage, which effectively prolongs the life of the milling cutter.
Small volume hydraulic oil tank design, low maintenance cost.
Safety
Equipped with functions such as reversing image as standard, the construction is safer.
The four-column lifting system adopts a large stroke design, with good passability, and the upper and lower transport trolleys are safer.
The four-track braking system ensures more reliable braking of the whole machine.
Comfortable
The cooling system is designed with air blowing, and the air duct is far away from the operating table.
Rotating seat, multi-station setting, no blind spot for operation.
The display is installed independently, can be raised and lowered, and rotated in multiple dimensions.
Parameter name | 2m road planer SM200M-C6N |
Performance parameters | |
Working mass(kg) | 33000 |
Transport mass (kg) | 30000 |
Max. Milling width (mm) | 2000 |
Max. Milling depth(mm) | 330 |
Engine | |
Engine model | QSX15 |
Rated power/rated speed (kw/rpm) | 470/2100 |
Dimensions | |
Overall dimensions of the whole machine(mm) | 14740*2830*4090 |
Walking performance | |
Riving speed(km/h) | 0-5 |
Working speed (km/h) | 0-85 |
Feeding system | |
Conveyor belt width (mm) | 850 |
Feeder swing angle(right/left)(°) | ±65 |
Fuel tank capacity | |
Fuel tank (L) | 1120 |
Working equipment | |
Number of milling cutters(pieces) | 148 |
