Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of shantui road planer in China. Please feel free to buy cheap shantui road planer for sale here from our factory. Quality products and reasonable price are available.
Technical Features
Efficient
Shantui Road Planer 103KW engine is equipped with a working weight of 6.6 tons and has a strong working capacity.
Excellent milling drum design, high milling efficiency and low vibration.
Large traction force and strong milling ability at large depths.
The minimum milling radius is 300mm, and the steering is flexible.
Shantui Road Planer SMT50-C6N comes standard with pneumatic tool changer, easy and efficient
Intelligent
CAN bus network control.
Shantui Road Planer SMT50-C6N comes standard with controller and display.
The job parameters are centrally displayed digitally.
Shantui Road Planer SMT50-C6N has a complete fault self-diagnosis and alarm and prompt system.
Affordable
Shantui Road Planer SMT50-C6N comes with its own air source to clean the air filter anytime, anywhere.
The maintenance parts are standardized and have a high degree of generalization.
The tool holder has a positioning function, which is convenient for maintenance and low in cost.
Safety
Large ground clearance of 245mm, good passability.
The steering mechanism has a large safety factor and high reliability.
Constant pressure protection of water system, long life of pump.
Advanced fuel tank anti-rust technology, high system cleanliness.
Comfortable
Good noise reduction design, low noise in the driver's ear.
The operating table is equipped with LED lights, and the construction at night is barrier-free.
Folding seat, more spacious operating channel.
Parameter name | SHANTUI road planer SMT50-C6N(standard version) |
Performance parameters | |
Working mass(kg) | 6600 |
Transport mass (kg) | 6280 |
Max. Milling width (mm) | 500 |
Max. Milling depth(mm) | 180 |
Engine | |
Engine model | WP4.1 |
Rated power/rated speed (kw/rpm) | 103/2300 |
Dimensions | |
Overall dimensions of the whole machine(mm) | 3310*2130*2460 |
Walking performance | |
Riving speed(km/h) | 0-8 |
Working speed (km/h) | 0-50 |
Feeding system | |
Conveyor belt width (mm) | - |
Feeder swing angle(right/left)(°) | - |
Fuel tank capacity | |
Fuel tank (L) | 190 |
Working equipment | |
Number of milling cutters(pieces) | 54 |
