Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of tarmac roller in China. Please feel free to buy cheap tarmac roller for sale here from our factory. Quality products and reasonable price are available.
The Tarmac Roller uses LiuGong's unique shock-free exciter. The design of the Tarmac Roller avoids impact noise, prevents metal fragments generated by the impact from contaminating the bearing lubrication system, reduces the risk of eccentric block breakage, and extends the exciter and vibration time. Service life of bearings and eccentric shafts.
Tarmac Roller has an ECO energy-saving mode and uses intelligent power matching to match the best power under different loads and reduce fuel consumption.
Parameter name | 6114E |
Operating Mass | 14000 kg |
Mass On Vibrating Drum | 7000 kg |
Mass On Drive Axle | 7000 kg |
Front Drum Static Linear Load | 322 N/cm |
Model | Shangchai SC4H140.2G2 |
Emission Regulation | Stage II |
Rated Power | 103 kW (140 hp) @ 2000 rpm |
Vibration Frequency | 30 Hz |
Nominal Amplitude | 2.0/1.2 mm |
Centrifugal Force | 280/170 KN |
Drum Diameter | 1555 mm |
1st Maximum Speed, fwd | 2.7 km/h |
2nd Maximum Speed, fwd | 5.2 km/h |
3rd Maximum Speed, fwd | 11 km/h |
Theoretical Gradeability | 30% |
Min. Ground Clearance | 450 mm |
Wheelbase | 2950 mm |
Min. Outside Turning Radius | 6500 mm |
Overall Length | 6000 mm |
Overall Width | 2280 mm |
Overall Height | 3050 mm |
