Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of d6 dozer in China. Please feel free to buy cheap d6 dozer for sale here from our factory. Quality products and reasonable price are available.
Features:
D6 is suitable for the operation of push, excavation, backfilling, and other loose materials for roads such as highways, railways, mines, and airports. It is an indispensable mechanical equipment such as national defense engineering, mining construction, urban and rural roads and other construction construction and water conservancy construction
D6 vehicle beam is protected by seamless snake skin tube to improve the reliability of the electrical wire beam; the overall injection molding structure instrument table, integrate the air conditioning, electrical, and instrument boxes, beautiful and high -end; optimize the layout of working lights, improve the lighting of the vehicle Sexual; increase the alarm bell and work alarm to improve the safety warning when the vehicle works.
D6 host frame of the full -box structure has a high ability to carry impact load and anti -bending twist, and high -quality welds ensure that the host frame has a full life cycle.
PARAMETER
Parameter name | SD16 (Standard version) | SD16C (Coal version) | SD16E (Extended version) | SD16L（Super-wetland version） | SD16R (Environmental sanitation version) | SD16D (Desert version) |
Performance parameters | ||||||
Operating weight (Kg) | 17000 | 17500 | 17346 | 18400 | 18400 | 18200 |
Ground pressure (kPa) | 58 | 50 | 55 | 25 | 25 | 33.2 |
Engine | ||||||
Engine model | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) | WD10(China-II)/WP10(China-III) |
Rated power/rated speed (kW/rpm) | 131/1850 | 131/1850 | 131/1850 | 131/1850 | 131/1850 | 131/1850 |
Overall dimensions
| ||||||
Overall dimensions of machine (mm) | 5140*3388*3032 | 5427*3900*3032 | 5345*3388*3032 | 5262*4150*3074 | 5262*4150*3074 | 5262*4150*3074 |
Driving performance | ||||||
Forward speed (km/h) | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 | F1:0-3.29,F2:0-5.82,F3:0-9.63 |
Reversing speed (km/h) | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 | R1:0-4.28,R2:0-7.59,R3:0-12.53 |
Chassis System | ||||||
Center distance of track (mm) | 1880 | 1880 | 1880 | 2300 | 2300 | 2300 |
Width of track shoes (mm) | 510/560/610 | 610 | 560/510/610 | 1100/950 | 1100/660 | 810 |
Ground length（mm）
| 2430 | 2430 | 2635 | 2935 | 2935 | 2935 |
