Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 10 ton diesel forklift in China. Please feel free to buy cheap 10 ton diesel forklift for sale here from our factory. Quality products and reasonable price are available.
|
型 号 |
Model |
CPCD120 |
||
|
动力种类 |
Power |
柴油/Diesel |
||
|
额定起重量 |
Rated lifting load |
KG |
12000 |
|
|
载荷中心距 |
Load center distance |
mm |
600 |
|
|
驾驶方式 |
Driving mode |
座驾式/Seat driving |
||
|
全长 |
有货叉 L1 |
With fork |
mm |
5697 |
|
无货叉 L2 |
Without fork |
4477 |
||
|
全宽B |
Width |
2245 |
||
|
全高 |
不升起门架 H1 |
Height when the mast not raised |
2870 |
|
|
护顶架高度 H2 |
Overhead guard height |
2570 |
||
|
轴距 L4 |
Wheelbase |
3000 |
||
|
前悬距 Y |
Front overhang |
718 |
||
|
后悬距 L5 |
Rear overhang |
740 |
||
|
最小离地间隙(门架处) F |
Minimum ground clearance |
250 |
||
|
无载最大起升高度 H |
No-load maximum lifting height |
3000 |
||
|
自由起升高度H4 |
Free lifting height |
200 |
||
|
最小转弯半径(外侧WA |
Minimum turning radius (outer side) |
4400 |
||
|
最小直角通道宽度RA |
Minimum right angle aisle width |
5580 |
||
|
门架倾角(前/后) a/β |
Mast tilt angle (front/rear) |
(°) |
5°/10° |
|
|
无载最大升起速度 |
No-load maximum lifting speed |
mm/s |
320 |
|
|
满载最大升起速度 |
Full-load maximum lifting speed |
280 |
||
|
无载最大运行速度 |
No-load maximum working speed |
Km/h |
26 |
|
|
满载最大运行速度 |
Full-load maximum working speed |
20 |
||
|
满载最大爬坡度 |
Full-load maximum gradeability |
％ |
15 |
|
|
标准无载状态下整机质量 |
Forklift weight under standard no-load condition |
Kg |
14410 |
|
|
车轮数量(前/后) |
Tire no. (F/R) |
4/2 |
||
|
轮胎类型(前/后) |
Tire type (F/R) |
充气胎/Air inflation tire |
||
|
轮胎尺寸(前) |
Tire size (F) |
10.00-20NHS |
||
|
轮胎尺寸(后) |
Tire size (R) |
10.00-20NHS |
||
|
制动器/行车制动器 |
Brake/service brake |
动力制动-踏板/Power brake-pedal |
||
|
停车制动器 |
Parking brake |
机械-手动式/Machenical-manual |
||
|
蓄电池电压/容量 |
Battery voltage/capacity |
V/Ah |
2-12/80 |
|
|
发动机型号 |
Engine model |
锡柴CA6110 |
||
|
发动机燃油箱容量 |
Engine fuel tank capacity |
L |
190 |
|
