Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of rent excavator se220lc in China. Please feel free to buy cheap rent excavator se220lc for sale here from our factory. Quality products and reasonable price are available.
High-end system configuration
Cummins B5.9 six-cylinder engine, national II emission standard, strong power, durable, equipped with a three-level fuel filter system, escort.
Optimal negative flow control hydraulic system, reliable performance, easy to maintain;
Large displacement main pump and engine perfect match, the whole machine speed is faster.
Durable structural parts
1. Standard reinforced bucket
2. Front support casting form, strengthened sticking plate in key parts, better reliability.
3. The front fork and backseat of the movable arm adopt the casting box body, and bear the load of multi-directional variable torque.
4. X-shaped box structure of lower frame, strong bearing capacity, thickened plate in key parts, reliable and durable.
Comfortable and convenient operation environment
1.Equipped with USB radio, cigarette lighter, fire extinguisher, escape hammer, etc., equipped with multiple storage Spaces;
2.Centralized layout of function keys, convenient operation, beautiful and beautiful.
3.Large space, wide vision, reasonable arrangement of the control device, easy to operate and comfortable.
4.The seat is comfortable and anti-fatigue.
5.High-power electric automatic air conditioning, strong wind, multi - directional no dead - Angle air outlets.
Comparative item | SE220LC |
Overall dimensions | |
Overall length (mm) | 9615 |
Ground length (During transport) (mm) | 5025 |
Overall height (To the top of boom) (mm) | 3035 |
Overall width (mm) | 3180 |
Overall height (To top of cab) (mm) | 3045 |
Ground clearance of counterweight (mm) | 1055 |
Minimum ground clearance (mm) | 466 |
Tail turning radius (mm) | 2925 |
Track length (mm) | 4460 |
Track gauge (mm) | 2380 |
Track width (mm) | 3180 |
Standard track shoe width (mm) | 800 |
Turntable width (mm) | 2725 |
Distance from slewing center to tail (mm) | 2920 |
Working range | |
Maximum digging height (mm) | 10075 |
Maximum dumping height (mm) | 7165 |
Maximum digging depth (mm) | 6515 |
Maximum vertical digging depth (mm) | 5795 |
Maximum digging distance (mm) | 9865 |
Maximum digging distance at ground level (mm) | 9685 |
Working device minimum turning radius (mm) | 2970 |
Engine | |
Model | Cummins B5.9-C |
Type | Water cooled, six cylinder in-line, turbocharged |
Displacement (L) | 5.9 |
Rated power (kW/rpm) | 112/1950 |
Hydraulic system | |
Type of hydraulic pump | Variable piston pump |
Rated working flow (L/min) | 2x218 |
Bucket | |
Bucket capacity (m³) | 1.05 |
Swing system | |
Maximum swing speed (r/min) | 10.2 |
Brake type | |
Digging force | |
Bucket arm digging force (KN) | 92.5 |
Bucket digging force (KN) | 127 |
Operating weight and ground pressure | |
Operating weight (kg) | 22800 |
Ground pressure (kPa) | 35.3 |
Traveling system | |
Traveling motor | Axial variable plunger motor |
Traveling speed (km/h) | 3.2/4.7 |
Traction force (KN) | 203 |
Gradeability | 70% |
Tank capacity | |
Fuel tank capacity (L) | 330 |
Cooling system (L) | 28 |
Engine oil capacity (L) | 20 |
Hydraulic oil tank/system capacity (L) | 400 |
