Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 22ton road roller in China. Please feel free to buy cheap 22ton road roller for sale here from our factory. Quality products and reasonable price are available.
The 22ton road roller adopts Shangchai National III high-pressure common rail electronically controlled diesel engine to achieve the best fuel consumption working area, reduce the comprehensive fuel consumption by 10%, and have a large power reserve; reasonably match the transmission system to achieve the best compaction operation speed and improve operation efficiency. 8%;
The 22ton road roller adopts four-level braking, service brake, parking brake, emergency brake and auxiliary brake, among which the auxiliary brake is the end brake, which is safe and reliable;
The cab and the frame adopt a vibration damping device with combined stiffness, which reduces the vibration of the cab in multiple dimensions and significantly improves the working comfort of the operator;
The 22ton road roller adopts scientific and reasonable air duct design, the air-conditioning system independently dissipates heat to ensure sufficient air intake, comprehensively enhances the heat dissipation capacity, and ensures the efficient work of the power system;
The 22ton road roller adopts hydrostatic drive, which improves the operation comfort and stability of the whole machine;
22ton road roller uses advanced hydraulic damping control technology to optimize vibration parameters, work more smoothly, and greatly improve the quality of work;
As a whole, the new appearance of XCMG single-drum roller "5" series platform is adopted, which is beautiful and elegant.
Model | Unit | XS225H |
Operating weight | kg | 22000 |
Load applied on front drum | kg | 10000 |
Static linear load | N/cm | 470 |
Travel Speed | km/h | 3-9.4 |
Theoretical gradeability | % | 30 |
Min. outer turning radius | mm | 6500 |
Steering angle | ° | ±33 |
Oscillating angle | ° | ±10 |
Vibration frequency | Hz | 33/28 |
Nominal amplitude (high/low) | mm | 1.9/0.95 |
Exciting force (high/low) | kN | 353/245 |
Drum width | mm | 2130 |
Drum Diemeter | mm | 1600 |
Engine model | Shanghai Diesel Engine | |
Rater Power | kW | 147 |
Engine oil consumption | g/kW.h | 205 |
Hydraulic tank capacity | L | 170 |
Fuel tank capacity | L | 310 |
Dimension(L*W*H) | mm | 6220*2430*3200 |
