Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of wheel loades 5 ton in China. Please feel free to buy cheap wheel loades 5 ton for sale here from our factory. Quality products and reasonable price are available.
Power System
Weichai electronically controlled engine, the emission meets the national non-road machinery stage III emission requirements, is intelligent and efficient, has strong parts versatility, and low maintenance costs.
Wheel Loades 5 Ton is matched with three power modes of no-load, medium-load and heavy-load, which are selected according to the actual working conditions and load requirements to achieve a reasonable matching of power, efficiency and energy consumption.
Driving Environment
Wheel Loades 5 Ton fully-sealed cab has noise reduction, dustproof, heat insulation, wide field of vision, and is equipped with heating and cooling air conditioning, reversing camera, Bluetooth radio, etc., with low working noise. The sliding window on the right side of the cab is changed to an integral window type.
Wheel Loades 5 Ton seat has a wide range of adjustment, providing the driver with the most comfortable operating position.
The L58-B3 reasonably arranges the joystick, foot pedal and seat position, making the operation more comfortable.
Standard radios, stereos, watering cans, etc., provide a richer humanized driving experience, and the driving environment is comfortable and safe.
Operational Performance
The operation of the working device is flexible, light and comfortable, and the pilot single and double handles are optional to meet the needs of different customers
High Working Efficiency
L58-B3 adopts a new type of bucket, adds overflow plate, and optimizes the bucket shape to improve the full bucket rate and shovel loading efficiency.
Large tipping load, good dry heavy work stability and high efficiency.
Shantui's special Weichai electronically controlled engine and Shantui's self-made special speed-increasing gearbox achieve the best matching effect, good acceleration performance and fast speed-up of the whole machine. L58-B3 combined working condition (walking and action at the same time) has large traction and lifting force, strong explosive force and high working efficiency.
L58-B3 adopts dual pump confluence system working system and coaxial flow amplification steering system. The operation is sensitive, the steering speed is fast and stable; the working pressure is increased to 18MPa, the lifting force is increased by 12%, and the shovel operation efficiency is higher.
Reliable performance
The front and rear frames, working devices and other structural parts are optimized and strengthened, and the key components are analyzed by CAE. The main welding parts are all welded by robots, and the welding quality is reliable.
The hydraulic system components are all international and domestic well-known brands.
The electrical system is equipped with standard LED lamps, oil level display, GPS; optimized main power switch and reversing alarm bell.
The cooling system adopts a series integrated radiator, the space utilization is reasonable, and the heat dissipation efficiency is high. Radiator fin spacing is increased to reduce the risk of clogging and facilitate cleaning. Increase the diameter of the fan, increase the air volume, and improve the cooling performance of the system.
Easy Maintenance
L58-B3 increases the grease outlet pipeline, optimizes the maintenance position of the filter element, etc., which is convenient for daily maintenance and maintenance.
Performance Parameters | |||
L58-C3 SG | L58-C3 CH | L58-C3 MH | |
work quality(kg) | 17200 | 18000 | 17650 |
Max. Unloading height(mm) | 3200(standard arm)3450(Extended arm)3700(King Kong Long Arm) | 3210(Extended arm)3420(King Kong Long Arm) | 3215(standard arm)3260(Extended arm) |
Unloading distance(mm) | 1230(standard arm)1200(Extended arm)1270(King Kong Long Arm) | 1395(Extended arm)1510(King Kong Long Arm) | 1125(standard arm)1310(Extended arm) |
Max. Rising Power(kn) | ≥185 | ≥185 | ≥185 |
Three sum(s) | 10.5 | 10.5 | 10.5 |
Engine | |||
Engine model | WP10 | WP10 | WP10 |
Rated power/rated speed | 162/2000 | 162/2000 | 162/2000 |
Dimensions | |||
Overall dimensions(mm) | 8100*3020*3410 | 8460*3020*3410 | 8160*3075*3410 |
Walking performance | |||
Forward speed(km/h) | F1:0-13,F2:0-40 | F1:0-13,F2:0-40 | F1:0-13,F2:0-40 |
Backward speed(km/h) | R:0-15 | R:0-15 | R:0-15 |
undercarriage | |||
Wheelbase(mm) | 3300 | 3300 | 3300 |
Fuel tank capacity | |||
Fuel tank(L) | 300 | 300 | 300 |
Working equipment | |||
Rated bucket capacity(m³) | 3 | 4 | 2.5 |
Rated load capacity(t) | 5 | 5 | 5 |
