Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 190 kw motor grader in China. Please feel free to buy cheap 190 kw motor grader for sale here from our factory. Quality products and reasonable price are available.
Product Orientation
The "Hercules" among the small graders is suitable for general roadbed leveling conditions and meets "small investment, large return".
Product Feature
Great traction, quick transitions
Weichai 180-horsepower heavy-duty engine, optimal axle-to-load ratio, and 10% greater traction than similar products.
The maximum speed is 42km/h, and the shovel height is 480mm. It can be easily up and down without turning the shovel.
Fast blade action and precise operation
Large displacement working pump and rotary motor, the cylinder moves 20% faster and the blade rotates 30% faster. The handle and steering wheel of 190 kw Motor Grader STG170C require little control force, and the oil cylinder is responsive.
Maintenance and worry-free, low cost of use
190 kw Motor Grader STG170C adopts a new generation of desert filter, the filtration efficiency is increased by 10 times, and the air filter maintenance period is extended to more than 1000h. Slewing bearing structure, integral axle housing, NO-SPIN anti-skid differential, disc brake, safe and reliable.
Easy maintenance
190 kw Motor Grader STG170C has built-in troubleshooting guide and maintenance content, fault self-diagnosis fault information is directly displayed, and daily maintenance is automatically prompted.
Innovative Technology
Power adaptive energy saving technology
180 horsepower low-speed high-torque heavy-duty engine with strong power.
Gear and power intelligent matching technology, to achieve power according to the output, save 15% of fuel.
DC air intake technology
Ultra-Web Nano filter element, the filtration precision is increased by 10 times, effectively preventing the engine from premature grinding, and the maintenance cycle is 1000h. DC air intake technology reduces air intake resistance by 30% and fuel consumption by 3-5%, effectively preventing premature engine wear.
Slewing ring disc brake rear axle
The slewing bearing replaces the traditional copper sleeve structure and has no wearing parts. Integral axle housing, NO-SPIN anti-skid differential, heavy-duty chain + disc brake, safe and reliable.
Blade precise control technology
Load-sensing technology, the proportion of the effective stroke of the handle is increased to 60%, and the control force is reduced by 30%. The speed of the blade cylinder is controllable, achieving millimeter-level leveling accuracy and reducing the difficulty of operation by 30%.
Optimal structure working device
The blade of the 190 kw Motor Grader STG170C can easily go up and down without tipping over. The distance between the left and right sides of the blade is the largest in the industry, and the operating range is wide.
Safe and comfortable driving experience
190 kw Motor Grader STG170C with integral front windshield, left and right sliding windows, sun visors, sun shades, leather seats with headrests, heating and cooling air conditioners, fans, radios, multi-function storage boxes, USB fast charging, fire extinguishers, 7-inch large touch screen , reversing image, multi-language interface, troubleshooting guide, regular maintenance tips.
Basic parameters | Engine brand | WEICHAI |
Emission class | Country Ⅲ | |
Rated power/speed | 132.5/2200kw/rpm | |
Overall dimensions | 8880*2730*3360mm | |
Overall weight | 14500kg | |
Performance parameters | Forward speed | 5/8/13/20/28/42km/h |
Backward speed | 5/13/28km/h | |
Blade movement | length * string height | 3660*620mm |
Max. lift height | 480mm | |
Max. shovel depth | 630mm | |
Max. tilt angle | ±90° | |
Cutting angle range | 25-75° | |
Slewing angle | 360° | |
Ripper | Max. immersion depth | 462mm |
Max. lift height | 526mm | |
Max. departure angle | 14° | |
Max. working width | 2180mm | |
Bulldozer | Max. immersion depth | 220mm |
Max. lift height | 625mm | |
Max. entry angle | 63° | |
Max. working width | 2740mm | |
The main parameters | Engine | WEICHAI WP6 |
Overall weight | 14500KG | |
Blade length | 3660mm |
