Famous Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 18 ton crane truck in China. Please feel free to buy cheap 18 ton crane truck for sale here from our factory. Quality products and reasonable price are available.
Product Features
Excellent lifting performance
The lifting performance is better than that of the luffing tower crane of the same level (such as 60 meters long jib), and the hoisting weight of the jib tip is 3.0t/2.71t.
High lift
The wire rope capacity reaches 710m, which meets the height requirements of most super high-rise buildings at home and abroad.
The hoisting and luffing ropes are arranged neatly, which greatly improves the life of the wire rope.
Diversified configuration
18 ton crane truck L250-20 has two options of 20t and 16t maximum lifting capacity.
There are seven boom length combinations of 60/55/50/45/40/35/30 m.
The balance arm can install both concrete counterweight and steel plate counterweight.
High degree of intelligence
Fault self-diagnosis technology, when the 18 ton crane truck L250-20 fails, the current fault and historical fault can be inquired through the fault record, and the cause of the fault can be diagnosed and eliminated through the mechanism detection.
Remote management technology realizes equipment information management, including working conditions, alarm data recording, tracking and analysis, remote control and other information.
Excellent lifting performance
The boom length has excellent lifting performance. The 60m boom length can lift 2.71t and the maximum lifting capacity is 20t.
The boom length combination is rich, the longest boom is 60m, the 5m variable boom length, the shortest 30m, and 7 types of boom length combinations.
The luffing and hoisting are fast, the luffing time is 22min, and the maximum hoisting speed is 100m/min.
Safe and reliable
The lifting weight and torque are multiple protected to prevent overloading.
The luffing triple protection prevents the 18 ton crane truck L250-20 from tipping over.
The boom pin shaft connection has strong resistance to sudden unloading and accidental collision.
High degree of intelligence
Fault self-diagnosis technology, when the 18 ton crane truck L250-20 fails, the current fault and historical fault can be inquired through the fault record, and the cause of the fault can be diagnosed through the mechanism detection, and the safety monitoring system can be configured to eliminate the fault.
Configure hoisting mechanism motor over-temperature status recognition and alarm.
Rated liftingmoment (t.m) | 250 | ||||||
Max. lifting height (m) | Free-standing stationary crane | 52.85 | |||||
Anchored crane | 165.35 | ||||||
Working radius (m) | Max. working radius | 60 | |||||
Min. working radius | 3.3 | ||||||
Max. lifting capacity (t) | 20 | ||||||
Hoisting mechanism | Rope fall | α＝2 | α＝4 | ||||
Speed (m/min) | 0~40 | 0-80 | 0-100 | 0-20 | 0-40 | 0-50 | |
Lifting weight (t) | 10 | 5 | 2.5 | 20 | 10 | 5 | |
Power (kW) | 75 | ||||||
Slewing mechanism | Speed (m/min) | 0-0.61 | |||||
Power (kW) | 2*7.5kw | ||||||
Trolleying mechanism | Speed (m/min) | 2.2(15° -85° ) | |||||
Power (kW) | 45 | ||||||
